Lifting of any load, pushing or pulling of mechanical equipment, adjusting of tight clearances of mechanical parts
Shenzhen, Guangzhou, Hongkong
20000 Piece Per Day
Contact us for information regarding our sample policy
100% standard exporting plywood cases.
Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
0.5-Ton Worm Gear Trapezoidal Screw Jack Main components of screw jacks are trapezoidal lifting screw, worm screw, worm gear and gear housing. Worm screw is rotated manually or by motor. Worm gear is rotated by worm screw. The lifting screw moves through the rotating worm gear. The linear motion speed of lifting screw depends on thread size and rotation ratio of worm gears.
Features: 1. Maximum lifting capacities 0.5 ton 2. Lifting screw sizes Tr 20x5 3. Worm gear ratios 1:5, 1:10, 1:20 4. Custom made lifts height 10-1500mm 5. End fittings: top plate, clevis end, threaded end, plain end, forked head and rod end 6. Screw designs: translating, keyed, rotation screw design 7. Power source: manually operation (hand wheel) or electrically operated (electric motor) 8. Single unit or multiple units 0.5 Ton Acme Screw Jack lifting system arrangements
