3 Post Lifting Points Worm Gear Screw Jack System

Product Details:

X

Product Description

We provides the complete set 3 Post Lifting Points Worm Gear Screw Jack System which accessories include three screw jacks, miter gearboxes, couplings, connecting shafts, pillow blocks, handwheels or electrical motors etc. Three lifting points systems are not only for the simple load-supporting from several kilograms to heavy duty several hundreds tons, but also have other features such as self-locking without brake or locking mechanism, precisely positioning, easy installation and operation, maintenance free, can be operated by hand wheels, 3-phase motor or both.

Configurations
* I configuration: 3pcs screw jacks, 5pcs couplings, 2pcs connecting shafts, 1pc electric motor (electrically) or 1pc hand wheel (manually).
* L configuration: 3pcs screw jacks, 6pcs couplings, 2pcs connecting shafts, 1pc bevel gearbox, 1pc electric motor (electrically) or 1pc hand wheel (manually).
* T configuration: 3pcs screw jacks, 6pcs couplings, 1pc bevel gearbox, 2pcs connecting shafts, 1pc electric motor (electrically) or 1pc hand wheel (manually)
* TL configuration: 3pcs screw jacks, 6pcs couplings, 1pc bevel gearbox, 2pcs connecting shafts, 1pc electric motor (electrically) or 1pc hand wheel (manually).
* TI configuration: 3pcs screw jacks, 7pcs couplings, 1pc bevel gearbox, 3pcs connecting shafts, 1pc electric motor (electrically) or 1pc hand wheel (manually).
* TT configuration: 3pcs screw jacks, 9pcs couplings, 2pcs bevel gearboxes, 4pcs connecting shafts, 1pc electric motor (electrically) or 1pc hand wheel (manually).
Note: When connecting shafts length is exceed maximum distance of between supports, Pillow blocks are required.

JACTON INDUSTRY CO., LTD.

* Tips on getting accurate quotes. Please include product name, order quantity, usage, special requests if any in your inquiry.
