Jth110 Right Angle Gearbox Hollow Shaft Arrangement 1: 1 Ratio Hollow Bore Right Angle Drive

Product Details:

X

Product Description

JTH110 right angle gearbox hollow shaft arrangement 1:1 ratio hollow bore right angle drive features:
1. Maximum allowable torque 78N.m, Maximum allowable power 11kw, Maximum allowable speed 1500rpm.
2. Standard solid input shaft diameter 22mm, customized smaller or larger sizes input shafts.
3. Maximum allowable hollow shaft diameter 22mm, customized smaller sizes hollow shafts.
4. Cubic housing, 110mm square box, with all-round tapped holes for universal mounting, 6 possible universal mounting positions, can be easily mounted in any direction.
5. Standard bevel gear ratios 1:1 and 2:1, custom made 1.5:1, 3:1, 4:1 and 5:1 reduction ratios.
6. Drive shafts arrangements available 2-way, 3-way, and 4-way.
7. Drive shafts can be rotated in both clockwise and counter-clockwise rotation direction.
8. Quiet low noise, low backlash, low running temperature.

JTH110 right angle gearbox hollow shaft arrangement 1:1 ratio hollow bore right angle drive Dimensions
1. Standard solid input shaft diameter 22mm, customized smaller or larger sizes input shafts.
2. Maximum allowable hollow shaft diameter 22mm, customized smaller sizes hollow shafts.
