Jth170 90 Degree Gearbox Hollow Shaft 2: 1 Ratio Vertical Hallow Shaft Right Angle Gear Drive

Product Details:

X

Product Description

JTH170 90 degree gearbox hollow shaft 2:1 ratio vertical hallow shaft right angle gear drive features:
1. Maximum allowable torque 290N.m, Maximum allowable power 39kw, Maximum allowable speed 1500rpm.
2. Standard solid input shaft diameter 40mm, customized smaller or larger sizes input shafts.
3. Maximum allowable hollow shaft diameter 38mm, customized smaller sizes hollow shafts.
4. Cubic housing, 170mm square box, with all-round tapped holes for universal mounting, 6 possible universal mounting positions, can be easily mounted in any direction.
5. Standard bevel gear ratios 1:1 and 2:1, custom made 1.5:1, 3:1, 4:1 and 5:1 reduction ratios.
6. Drive shafts arrangements available 2-way, 3-way, and 4-way.
7. Drive shafts can be rotated in both clockwise and counter-clockwise rotation direction.
8. Quiet low noise, low backlash, low running temperature.

JTH170 90 degree gearbox hollow shaft 2:1 ratio vertical hallow shaft right angle gear drive Dimensions
1. Standard solid input shaft diameter 40mm, customized smaller or larger sizes input shafts.
2. Maximum allowable hollow shaft diameter 38mm, customized smaller sizes hollow shafts.
