Jth240 Angle Gearbox Hollow Shaft 1 to 1 Ratio 90 Degree Gearboxes Hollow Shafts

200.00 - 2000.00 USD ($)/Piece

Product Details:

X

Price And Quantity

  • 1 Piece
  • 200.00 - 2000.00 USD ($)/Piece

Trade Information

  • 20000 Piece Per Day
  • 15 Days

Product Description

JTH240 angle gearbox hollow shaft 1 to 1 ratio 90 degree gearboxes hollow shafts features:
1. Maximum allowable torque 694N.m, Maximum allowable power 90kw, Maximum allowable speed 1500rpm.
2. Standard solid input shaft diameter 55mm, customized smaller or larger sizes input shafts.
3. Maximum allowable hollow shaft diameter 55mm, customized smaller sizes hollow shafts.
4. Cubic housing, 240mm square box, with all-round tapped holes for universal mounting, 6 possible universal mounting positions, can be easily mounted in any direction.
5. Standard bevel gear ratios 1:1 and 2:1, custom made 1.5:1, 3:1, 4:1 and 5:1 reduction ratios.
6. Drive shafts arrangements available 2-way, 3-way, and 4-way.
7. Drive shafts can be rotated in both clockwise and counter-clockwise rotation direction.
8. Quiet low noise, low backlash, low running temperature.

JTH240 angle gearbox hollow shaft 1 to 1 ratio 90 degree gearboxes hollow shafts Dimensions
1. Standard solid input shaft diameter 55mm, customized smaller or larger sizes input shafts.
2. Maximum allowable hollow shaft diameter 55mm, customized smaller sizes hollow shafts.
